Graco Magnum XR5, XR7, XR9 Repair Parts

XR5 Part Number (232740) Series A, B, C, D, E
XR7 Part Number (232745) Series A, B, C, D
XR9 Part Number (232750) Series A, B, C, D

Click HERE for the Magnum XR5 XR7 XR9 Manual

Graco 288-818 Magnum Pump Kit Old# 243-090 Used on the Following Sprayers Magnum XR5 XR7 XR9 Pro X7 Pro X9

288-818 Magnum Pump Kit Old# 243-090

$ 94.25

Graco 245-070 Inlet Valve XR5 XR7 & XR9 OLD# 243-093

245-070 Inlet Valve XR5 XR7 & XR9 OLD# 243-093

$ 47.30

Graco 103-413 Inlet Valve O Ring #020

#020 O Ring Inlet Valve & Pickup Tube

$ 1.95

Graco 243-094 Magnum Outlet Valve Used on the Following Sprayers Magnum XR5, XR7, XR9, Pro X7 Pro X9

243-094 Magnum Outlet Valve

$ 41.60

Graco 103-338 Outlet Valve O Ring #013

#013 O Ring Outlet / Inlet Valve 103338

$ 1.95

Graco 235014 Prime Valve Kit

235-014 Prime Valve Kit

$ 112.50

20-2806 Prime Valve Same as Graco 235-014 & 239-914

20-2806 Prime Valve 235-014 & 239-914

$ 84.95

Graco 224-807 Prime Valve Base

224-807 Prime Valve Base

$ 6.15

Graco 111600 Prime Valve Handle Pin

111-600 Prime Valve Handle Pin

$ 2.50

Graco 187-625 Prime Valve Handle

187-625 Prime Valve Handle

$ 8.00

14-2650 Magnum Outlet Filter Old# 243-070 Same as Graco 288747

14-2650 Magnum Outlet Filter 288747

$ 5.95

Graco 24Y327 Filter Adapter Kit

24Y327 Filter Adapter Kit

$ 20.60

Graco 115-719 O Ring #015

#015 O Ring Outlet Fitting & Inlet Valve

$ 1.95

14-3247 Magnum Inlet Strainer Same as Graco 288716

14-3247 Magnum Inlet Strainer

$ 8.95

Graco 24V074 Pickup Assembly X5

24V074 Pickup Assembly Carry Sprayers

$ 47.60

Graco 197-607 Magnum DX X5 Pickup Hose

197-607 Magnum Pickup Hose (Carry Sprayers)

$ 29.30

Graco 195-084 Magnum 28" Prime Hose

195-084 Magnum 28" Prime Hose

$ 4.75

Graco 24V074 Pickup Set X7 ProX17 Prox19

24V073 Pickup Set X7 ProX17 Prox19

$ 28.90

Graco 15D671 14 1/2" Pickup Tube XR7 & XR9

15D671 14 1/2" Pickup Tube XR7 & XR9

$ 12.50

Graco 195-108 Magnum 15" Prime Hose

195-108 Magnum 15" Prime Hose

$ 2.55

Graco 116-295 Magnum Inlet Hose Clamp

116-295 Inlet Hose Clamp

$ 2.65

Graco 115-099 Pickup Hose Gasket

10-3019 Pickup & TexSpray Hose Gasket (Same as 115-099)

$ 0.30

Graco 195-400 Magnum Hose Clip

195-400 Prime Hose Clip

$ 0.80

Graco 115-489 Magnum Prime Hose Clamp

115-489 Magnum Prime Hose Clamp

$ 2.45

Graco 244-035 Prime Hose Deflector

244-035 Prime Hose Deflector

$ 3.30

Graco 196-025 Magnum Yoke

196-025 Magnum Yoke

$ 10.80

Graco 194-503 Magnum Yoke Guide Pin

194-503 Magnum Yoke Guide Pin

$ 3.05

Graco 244-267 Magnum Pressure Control

244-267 Magnum Pressure Control

$ 135.50

Graco 119277 16 Amp Fuse

119-277 16 Amp Fuse

$ 2.45

Graco 243-229 Board XR5 XR7 XR9 Upgrade Board of 243228

243-229 Board XR5 XR7 XR9

$ 142.00
